Features
- AES/EBU and DMX-conformant, highly flexible
- Double shielding with copper braided and 100% AL fleece shielding
Technical Data
| Jacket, diameter | PVC 5.8 mm |
| AWG | 24 |
| No. of inner conductors | 2 x 0.22 mm² |
| Copper strand per conductor | 28 x 0.10 mm |
| Conductor insulation | PE 1.70 mm |
| Shielding | Tin copper braided shielding with 64 x 0.10 mm + AL/PT-foil+ drain wire 7 x 0.20 mm tin copper |
| Shielding factor | 100 % |
| Temperature range | Min. -20 °C |
| Temperature range | Max. +70 °C |
| Packaging | 100/300 m roll |
Electrical Data
| Capac. cond./cond. per 1 m | 50 pF |
| Capac. cond./shield. per 1 m | 108 pF |
| Cond. resistance per 1 m | 76.26 mΩ |
| Shield. resistance per 1 m | 29.62 mΩ |
| اللون | Black |
| Length | 100m |
