The EclFresnel CT+ XLIP stands out as a bright IP65-rated Fresnel hard source, crafted to replace traditional 5K Tungsten and 2.5K HMI lighting in film sets and large-scale indoor and outdoor setups. At the heart of this fixture is a robust 1500W (driven @1200 W) LED source, featuring 6 color emitters.
Its design with integrated power supply simplifies installation and wiring for both on-location use and permanent installations.
EclFresnel CT+ XLIP boasts a 300mm (12 inches) glass Fresnel lens, offering an impressive zoom range from 10° to 90° and 44.000 fixture lumens. This design maintains high efficiency even at narrow beam angles, ensuring a bright output at long throw projection.
For jobs that demand maximum punch, the fixture also accepts optional 30° and 60° open‑face reflector lenses, boosting luminous flux while preserving homogeneous colour mixing
Powered by Spektra Os, this luminaire guarantees light consistency, delivering a higher luminous flux across colors and whites. This results in a broader color space and a richer light spectrum, achieving exceptional values in CRI, TLCI, SSI, and TM30 indices, meeting the highest professional lighting requirements.
Enhanced with a more powerful processing unit, the EclFresnel CT+ range offers an unparalleled user experience. It provides refined control over light and color, complemented by more intuitive standalone operations. This is achieved through a larger display, backlit encoders, and advanced connectivity options, both wired and wireless.
EclFresnel CT+ also operates silently, making it an essential, durable workhorse for large film sets, theaters, and studio applications.
The EclFresnel CT+ XLIP stands out as a bright IP65-rated Fresnel hard source, crafted to replace traditional 5K Tungsten and 2.5K HMI lighting in film sets and large-scale indoor and outdoor setups. At the heart of this fixture is a robust 1500W (driven @1200 W) LED source, featuring 6 color emitters.
Its design with integrated power supply simplifies installation and wiring for both on-location use and permanent installations.
EclFresnel CT+ XLIP boasts a 300mm (12 inches) glass Fresnel lens, offering an impressive zoom range from 10° to 90° and 44.000 fixture lumens. This design maintains high efficiency even at narrow beam angles, ensuring a bright output at long throw projection.
For jobs that demand maximum punch, the fixture also accepts optional 30° and 60° open‑face reflector lenses, boosting luminous flux while preserving homogeneous colour mixing
Powered by Spektra Os, this luminaire guarantees light consistency, delivering a higher luminous flux across colors and whites. This results in a broader color space and a richer light spectrum, achieving exceptional values in CRI, TLCI, SSI, and TM30 indices, meeting the highest professional lighting requirements.
Enhanced with a more powerful processing unit, the EclFresnel CT+ range offers an unparalleled user experience. It provides refined control over light and color, complemented by more intuitive standalone operations. This is achieved through a larger display, backlit encoders, and advanced connectivity options, both wired and wireless.
EclFresnel CT+ also operates silently, making it an essential, durable workhorse for large film sets, theaters, and studio applications.
Features:1500W (driven @1200 W) 6 color LED Fresnel
300mm/12'' glass lens with 10-90° manual zoom, Optional Open Face reflectors
IP65 for indoor and outdoor use
New UI with 2.8'' display and 4 backlit pushable encoder
- Source:1'500W - drv@1'200W6 colour LEDs source
- Luminous flux:(10°) 22'322 lm - (90°) 43'642 lm@4.000 K
- Lux:(10°) 18'113 lx - (90°) 1'485lx@5m 4.000 K
- CRI:95 @3.200K; 98 @5.600K
- R9:98 @3.200K; 97 @5.600K
- TLCI:95 @3.200K; 98 @5.600K
- TM30 Rf:>93 @3.200K; >93 @5.600K
- TM30 Rg:<103 @3.200K; <103 @5.600K
- Source life expectancy:> 50.000 hrs (L70B10 @Ta 25° C / 77° F)
- Zoom range:10° - 90°manual
- Lens diameter:300mm
- Lens type:AR-coated glass Fresnel lens providing a classic soft light fall-off
- Other:spigot, barndoor and gel frame included
- Colour control:XY, CCT, Gel with Source Emulation, Tungsten emulation, HSI, User preset
- Colour mixing:6 colour LEDs source
- CCT:linear CCT adjustment from 1.850 K-20.000K
- Supported Protocols:DMX512, RDM, CRMX
- RDM:for remote addressing and parameter configuration
- Display:2.8'' Color display
- Stand Alone:4 pushable RGB backlit encoder
- Master/Slave:for synchronised operation of more units linked in a chain
- Dimmer:linear 0 - 100% electronic dimmer
- Dimmer curves:6selectable dimming modes available
- Strobe / shutter:1 - 30Hz, electronic
- Selectable PWM:1282 to 40000 Hz (selectable steps)
- Firmware upgrade:via DMX with UPBOXPRO (not included)
- Power connection:Seetronic powerCON TRUE IP65 IN
- Signal connection:IP65Seetronic XLR 5p IN/OUT connectors
- Wireless Connection:integrated LumenRadio TimoTwo FX - CRMX, CRMX² (RX only) and W-DMX compatible, Bluetooth enabled
- Data connection:IP65WEIPU SF12 4P-F
- Low Voltage DC connector:48V WEIPU SY25 4P connector
- Mains power supply:100-240V - 50/60Hz
- Low Voltage DC mains:48V (WEIPU SY25 4P connector)
- Max power consumption (230V):1260W
- Standby power:7,5 W
- Power factor:> 0,97
- IP rating:IP65 for temporary outdoor use (*)
- Cooling:heat pipe with low-noise fan
- Housing:Weatherproof IP65 construction with die-cast magnesium alloy
- Finish:black (RAL 9004)
- Operating temperature:Ta-20 to +45 °C (-4 to +113 °F)
- Dimensions (WxHxD):485x676x583mm
- Weight:27,7kg
- Bracket system:Sliding bracket for adjustable weight balance and handle on the top of the body for easy transportation
- Hardware on-board:filter frame, 8 doors barndoor, spigot
- Other:Handle on the top, double safety system on the front for the accessories, strengthened zoom movement system for enhanced durability and stability
- Compliance:CE, RCM, FCC, cTUVus
- NOTE:Suitable for permanent outdoor use, provided installation and maintenance cycles by qualified technicians are carried.
