Prolights CONTROLGO

وحدة تحكم DMX محمولة 1-Universe، مدير RDM، CRMX وتعمل بالبطارية

بالعرض فقط

إضافة إلى قائمة الأمنيات

عرض على موقع الشركة المصنّعة

رمز المنتج: CONTROLGO

العلامة التجارية: Prolights

الضمان 2 سنوات

دعم متخصص دعم ما قبل وما بعد البيع

استشر خبيراً

فريقنا جاهز لمساعدتك.

استشر خبيراً

فريقنا جاهز لمساعدتك.

اتصل بنا

تحتاج عرض سعر؟

سنوفر لك تسعيرة مخصصة لمشروعك.

طلب عرض سعر

ControlGo is the ultimately flexible, multi functional lighting controller. This incredibly versatile, simple to use tool combines a fixture remote, RDM Tool, CRMX transmitter, DMX controller and DMX recorder into a single, portable and durable device.

Whether flashing out a film set, setting addresses on a tradeshow stand, or controlling battery uplighters, the ControlGO is THE device you need to get up and running quickly and easily.

Taking power from a host of options - NP-F or V-Lock batteries, DC 12-48V or USB-C - you won't find a place you cant find some power.

Featuring wired and CRMX wireless DMX & RDM, the ControlGO is compatible with up to 42 fixtures of any brand over 1 Universe. Its intuitive touchscreen interface, plus physical buttons and encoders, gives fast, easy and accurate access to its functions.

From Film sets to events … Lights, Control, Go!

One Universe DMX Controller , RDM controller, DMX recorder, Remote UI

5'' touchscreen with 4 RGB encoders and physical buttons for unprecedented user experience

Signal output through XLR, Wireless CRMX, and remote UI connector

Power sources: NP-F batteries (batteries not included), V-mount adapter plate, 48V DC remote UI, 12-48V DC input through SF6-M 4p, USB type-C 5-12V power input (power cable not included)

Whether flashing out a film set, setting addresses on a tradeshow stand, or controlling battery uplighters, the ControlGO is THE device you need to get up and running quickly and easily.

Taking power from a host of options - NP-F or V-Lock batteries, DC 12-48V or USB-C - you won't find a place you cant find some power.

From Film sets to events … Lights, Control, Go!

Features:
One Universe DMX Controller , RDM controller, DMX recorder, Remote UI
5'' touchscreen with 4 RGB encoders and physical buttons for unprecedented user experience
Signal output through XLR, Wireless CRMX, and remote UI connector
Power sources: NP-F batteries (batteries not included), V-mount adapter plate, 48V DC remote UI, 12-48V DC input through SF6-M 4p, USB type-C 5-12V power input (power cable not included)

CONTROL SURFACE

On-board Screen:

5
”

Full Color Touchscreen

SOFTWARE

DMX Channels:

512
ch

CONNECTIVITY

DMX out:

1

universe

CONTROL

Supported Protocols:

DMX512, RDM, CRMX + WDMX
DMX channels:

512
ch
RDM:

for remote addressing and parameter configuration
Display:

5" Touch LCD
Other:

4 rotary push-encoders with RGB backlight

ELECTRONICS

Firmware upgrade:

via DMX with UPBOXPRO/UPBOX1 (not included), via USB pen drive or onboard memory

BATTERY

Battery:

7.2
V

NP-F550/F570/F750/F770/F960/F970 type battery or V-Mounts (14.4V) via dedicated accessory
Other:

Batteries not included with the device.

CONNECTIONS

Signal connection:

Seetronic XLR 5p OUT connector
Wireless Connection:

integrated LumenRadio TimoTwo FX - CRMX, CRMX² (RX only) and W-DMX compatible, Bluetooth enabled
Data:

1x

USB port
Low Voltage DC connector:

Weipu SA6(12-48V), Weipu SA12 (48V - RemoteConnector), USB type C PD3.0, Battery slots

ELECTRICAL

Low Voltage DC mains:

12-48V via DC IN, 48V via Remote Connector, 5-9-12-20V via PD3.0 over USB-C, 7.2V via battery slots
Max power consumption (230V):

8
W

PHYSICAL
