The Aether Link is a versatile, IP66 rated single universe wireless CRMX transceiver, fully compatible with Lumen Radio CRMX as well as Wireless DMX G3 and G4S protocols.

Designed in a compact form factor, it features moulded IP67 cables that provide flexible power and signal management, making it ideal for permanent architectural and outdoor installations.

The Aether Link also offers a simple, intuitive user interface with status LEDs and a push button, allowing quick and easy configuration of wireless settings.

Single universe wireless CRMX transceiver unit

Easy setup via one-button interface

IP66 rated for exterior installation

Power IN/Out and DMX In/Out through moulded IP67 cables

The Aether Link is a versatile, IP66 rated single universe wireless CRMX transceiver, fully compatible with Lumen Radio CRMX as well as Wireless DMX G3 and G4S protocols.

Designed in a compact form factor, it features moulded IP67 cables that provide flexible power and signal management, making it ideal for permanent architectural and outdoor installations.

The Aether Link also offers a simple, intuitive user interface with status LEDs and a push button, allowing quick and easy configuration of wireless settings.

Features:
Single universe wireless CRMX transceiver unit
Easy setup via one-button interface
IP66 rated for exterior installation
Power IN/Out and DMX In/Out through moulded IP67 cables

CONTROL

Supported Protocols:

DMX512, RDM, CRMX
DMX channels:

512
ch
RDM:

for remote addressing and parameter configuration

ELECTRONICS

Firmware upgrade:

via DMX with UPBOXPRO (not included)

CONNECTIONS

Power connection:

15 cm, IP67

moulded IP power IN/OUT connectors
Signal connection:

20 cm, IP67

moulded IP signal IN/OUT connectors
Wireless Connection:

integrated LumenRadio TiMo FX RDM - CRMX and W-DMX compatible
Transmission range:

up to 80 meters in open field

ELECTRICAL

Mains power supply:

100-240V - 50/60Hz
Max power consumption (230V):

2
W
Standby power:

1,5 W

PHYSICAL

IP rating:

IP66 for outdoor installations
Housing:

Weatherproof IP66 construction with die-cast aluminium alloy, scratch-resistant C5M Marine Grade paint (as standard)
Finish:

black
Operating temperature:

Ta

-20 to +45 °C (-4 to +113 °F)
Dimensions (WxHxD):

154x33x54
mm
Weight:

0,4
kg
