Features
- Soft PVC jacket and cores twisted to a StarQuad grant a perfect winding
- Loss-free transmission due to the special stranding
- Easy to work with due to good insulation and numbered wiring
Technical Data
| Jacket, diameter | PVC 13.2 mm |
| AWG | 12 |
| No. of inner conductors | 4 x 4.0 mm² |
| Copper strand per conductor | 80 x 0.25 mm |
| Cond. PVC insulation, diameter | 4.0 mm |
| Temperature range | Min. -20 °C |
| Temperature range | Max. +70 °C |
| Packaging | 100/300 m roll |
Electrical Data
| Capac. cond./cond. per 1 m | 108 pF |
| Cond. resistance per 1 m | 3.9 mΩ |
| Length | 100m, 200m |
No reviews yet.
Specifications
| Length | 100m, 200m |
