SunBar 2000FC is an exceptionally powerful LED graphic strobe batten featuring also as static blinder and flood. SunBar 2000FC offers flexible control of beam coverage through an interchangeable lens system, passing from 120° wide to 40° beam increasing the light intensity up to x4.
Available in FC/RGBW versions and designed to deliver simply staggering light levels, this versatile fixture can provide an unbelievable punch over a huge area.
SunBar 2000FC is an exceptionally powerful LED graphic strobe batten featuring also as static blinder and flood. SunBar 2000FC offers flexible control of beam coverage through an interchangeable lens system, passing from 120° wide to 40° beam increasing the light intensity up to x4.
Available in FC/RGBW versions and designed to deliver simply staggering light levels, this versatile fixture can provide an unbelievable punch over a huge area.
Features:Staggering 126'000 lumen output (strobe) with 120° beam angle
Art-Net and DMX control
Graphic effects from 16 individually controllable groups of RGBW LEDs
- Source:1.024x1WRGBW LEDs
- Source CCT:W: 6.500K
- Luminous flux:Strobe without lens (peak) 126000 lm; Static ON without lens 25774; Strobe with lens (peak) 46200; Static ON with lens 19183
- Lux:(115°) 1'005 lx - (37°) 3'457lx@3 m full
- Lux:(115°) 362 lx - (37°) 1'244lx@5 m full
- Source life expectancy:> 30.000 h
- Beam angle:without lens 115°, with lens 37°
- Field angle:without lens 155°, with lens 84°
- Other:Mountable 40° lens reflector plate (included)
- White presets:2.800 K -10.000K
- Colour wheel:virtual colour wheel with macros
- Pixel patterns:pre-programmed static and dynamic pixel patterns
- FX generator:adjustable foreground/background colour, index, speed, direction
- Static mode:selection of static colour
- Manual mode:manual adjustment of colour
- Auto mode:built-in programs with execution speed adjustment
- Special features:Multi-layer pixel FX control
- Rotating gobos:dynamic patterns with speed and rotation control
- Supported Protocols:DMX512, RDM, Art-Net, Kling-Net
- DMX channels:from 4 ch to 87ch
- Pixel control:1 / 2 / 4 / 8 / 16individually select and control sections
- RDM:for remote addressing and parameter configuration
- Display:black TFT touch display
- Dimmer:linear 0 - 100% electronic dimmer
- Dimmer curves:4selectable dimming modes available
- Strobe / shutter:1 - 30Hz, electronic
- Selectable PWM:600 to 25000 Hz (selectable steps)
- Firmware upgrade with:via DMX with UPBOXPRO/UPBOX1 (not included)
- Power connection:Seetronic powerCON waterproof IN/OUT connectors
- Signal connection:Amphenol XLR 5p IN/OUT connectors
- Data connection:Art-NetRJ45 IN/OUT
- Mains power supply:100-240V - 50/60Hz
- Max power consumption (230V):strobe: 987 W - static: 610W
- Output (at 230V):3units on a single power line
- Max power consumption (120V):strobe: 1.065 W - static: 630W
- Output (at 120V):1units on a single power line
- Power factor:0,98
- IP rating:IP20
- Cooling:forced-air with low-noise fan
- Housing:Sturdy die-cast aluminium body
- Finish:black
- Operating temperature:Ta-10 to +45 °C (+14 to +113 °F)
- Dimensions (WxHxD):1000x75x231mm
- Dimensions with PO system (WxHxD):mm
- Weight:9,5kg
- Suspension and fixing:bracket for hanging and floor positioning (optional)
- Bracket system:floor stand bracket compatible with quick-lock Omega brackets
- Mounting points:quick-lock Omega sockets
- Compliance:CE, UKCA, RCM
